Overview

The public surface is intentionally small and readable. Most models follow familiar fit and predict patterns, while the autodiff system centers on a single scalar Value type.

Top-level exports:

Value
GradientDescentOptimizer
gradient_descent_step
trace_graph
computation_graph_svg
save_computation_graph_svg
computation_graph_dot
mean_squared_error
accuracy_score
r2_score
rng
plotting
LinearRegressionGD
LogisticRegressionGD
DecisionTreeClassifier
RandomForestClassifier
LinearSVM
KMeans
AgglomerativeClustering
MLP

Reading the signatures:

• X means a feature array, usually shaped (n_samples, n_features).
• y means targets or class labels.
• fit(...) returns the fitted model instance unless noted otherwise.
• Names ending in _ are learned or generated after fitting.
• ax=None means you may pass an existing Matplotlib axis, or let Learnify create one.

Back to contents Next: Quick start

Quick Start

from learnify import Value, computation_graph_svg

x = Value(2.0, label="x")
y = Value(-3.0, label="y")
z = ((x * y) + 4.0).tanh()
z.label = "z"

z.backward()
svg = computation_graph_svg(z)

• x and y are scalar autodiff nodes.
• z is a derived output node built from earlier operations.
• backward() computes gradients from z through the graph.
• computation_graph_svg(z) returns an SVG string for the graph rooted at z.

Back to contents Next: Installation

Installation

uv sync --dev

• uv sync --dev installs the package and development dependencies for local work.

Back to contents Next: Core API

Core API

Value

A scalar node in a computation graph.

Value(data, _children=(), op="", label="")

• data: the scalar value stored in the node.
• _children: parent nodes used internally to trace the graph.
• op: a short operation label such as "+" or "tanh".
• label: optional display text for graph output and debugging.

exp() -> Value
tanh() -> Value
relu() -> Value
sigmoid() -> Value
topo() -> list[Value]
zero_grad() -> None
backward(grad=1.0) -> None

• exp(), tanh(), relu(), and sigmoid() each return a new derived Value.
• topo() returns the connected graph in topological order.
• zero_grad() clears gradients across the reachable graph.
• grad in backward(grad=1.0) is the incoming output gradient and defaults to 1.0.

Graph Utilities

trace_graph(root) -> (nodes, edges)
computation_graph_svg(root, *, node_width=200, node_height=94, horizontal_gap=64, vertical_gap=28, padding=24) -> str
save_computation_graph_svg(root, path, **kwargs) -> Path
computation_graph_dot(root) -> str

• root: the output Value to trace or render.
• path: destination file path when saving an SVG.
• node_width and node_height: dimensions of each rendered node box.
• horizontal_gap and vertical_gap: spacing between nodes and layers.
• padding: outer margin around the SVG drawing.
• kwargs: forwarded from save_computation_graph_svg() into computation_graph_svg().

Optimization

gradient_descent_step(parameters, gradients, learning_rate) -> None
GradientDescentOptimizer(learning_rate=0.01)

step_values(parameters) -> None
zero_grad(parameters) -> None
step_arrays(parameters, gradients) -> None

• parameters: the arrays or Value objects to update.
• gradients: gradient arrays aligned with the array parameters.
• learning_rate: the gradient descent step size.
• step_values() updates autodiff parameters in place.
• zero_grad() clears gradients on a sequence of Value parameters.
• step_arrays() applies the same update rule to NumPy arrays.

Back to contents Next: Utilities

Utilities

Metrics

mean_squared_error(y_true, y_pred) -> float
accuracy_score(y_true, y_pred) -> float
r2_score(y_true, y_pred) -> float

• y_true: expected numeric values or labels.
• y_pred: predicted numeric values or labels to compare against y_true.

RNG

learnify.rng.seed(value) -> None
learnify.rng.rand(*shape) -> np.ndarray
learnify.rng.normal(loc=0.0, scale=1.0, size=None) -> np.ndarray
learnify.rng.integers(low, high=None, size=None) -> np.ndarray
learnify.rng.choice(a, size=None, replace=True, p=None) -> np.ndarray

• value: integer seed for Learnify's internal random generator.
• *shape: output dimensions for uniform random samples.
• loc and scale: mean and standard deviation for normal samples.
• low and high: lower and upper bounds for integer sampling, with high exclusive.
• size: output shape for normal(), integers(), or choice().
• a: the source array, sequence, or integer range for choice().
• replace: whether choice() samples with replacement.
• p: optional sampling probabilities for choice().

Back to contents Next: Models

Models

LinearRegressionGD

LinearRegressionGD(learning_rate=0.01, n_iterations=1000, fit_intercept=True)
fit(X, y) -> LinearRegressionGD
predict(X) -> np.ndarray
score(X, y) -> float

• learning_rate: step size for full-batch gradient descent.
• n_iterations: number of optimization updates.
• fit_intercept: whether to learn a bias term.
• X: feature matrix for training or prediction.
• y: target values for fitting or scoring.
• score() returns the model's R^2 value.

• Fitted attributes include weights_, bias_, and loss_history_.

LogisticRegressionGD

LogisticRegressionGD(learning_rate=0.1, n_iterations=1000, l2=0.0)
fit(X, y) -> LogisticRegressionGD
decision_function(X) -> np.ndarray
predict_proba(X) -> np.ndarray
predict(X, threshold=0.5) -> np.ndarray

• learning_rate: optimization step size.
• n_iterations: number of training updates.
• l2: L2 regularization strength.
• X: feature matrix for training or inference.
• y: binary class labels for fitting.
• threshold: cutoff used by predict() for the positive class.

• Fitted attributes include classes_, weights_, bias_, and loss_history_.
• This implementation supports binary classification only.

DecisionTreeClassifier

DecisionTreeClassifier(max_depth=None, min_samples_split=2, max_features=None, random_state=None)
fit(X, y) -> DecisionTreeClassifier
predict(X) -> np.ndarray
predict_proba(X) -> np.ndarray

• max_depth: optional limit on tree depth.
• min_samples_split: minimum number of samples required to split a node.
• max_features: feature sampling rule per split.
• random_state: seed for internal randomness.
• X: numeric feature matrix.
• y: class labels for training.

• Fitted attributes include classes_, root_, depth_, n_leaves_, feature_importances_, and n_features_in_.

RandomForestClassifier

RandomForestClassifier(n_estimators=10, max_depth=None, min_samples_split=2, max_features="sqrt", bootstrap=True, random_state=None)
fit(X, y) -> RandomForestClassifier
predict_proba(X) -> np.ndarray
predict(X) -> np.ndarray

• n_estimators: number of trees in the forest.
• max_depth, min_samples_split, and max_features: tree-building controls passed to each estimator.
• bootstrap: whether each tree uses bootstrap sampling.
• random_state: seed for forest construction.
• X: feature matrix.
• y: class labels.

• Fitted attributes include trees_, estimators_, feature_importances_, classes_, and n_features_in_.

LinearSVM

LinearSVM(learning_rate=0.01, regularization=0.01, epochs=1000)
fit(X, y) -> LinearSVM
decision_function(X) -> np.ndarray
predict(X) -> np.ndarray

• learning_rate: update size during optimization.
• regularization: weight penalty strength.
• epochs: number of passes through the optimization loop.
• X: feature matrix.
• y: binary class labels.

• decision_function() returns signed margins before thresholding.
• Fitted attributes include weights_, bias_, classes_, and loss_history_.
• This implementation supports binary classification only.

KMeans

KMeans(n_clusters=2, max_iter=100, tol=1e-4, random_state=None)
fit(X) -> KMeans
fit_predict(X) -> np.ndarray
predict(X) -> np.ndarray

• n_clusters: target number of clusters.
• max_iter: maximum number of refinement steps.
• tol: convergence tolerance for center movement.
• random_state: seed for center initialization.
• X: numeric feature matrix to cluster.

• Fitted attributes include cluster_centers_, labels_, and inertia_.

AgglomerativeClustering

AgglomerativeClustering(n_clusters=2, linkage="average")
fit(X) -> AgglomerativeClustering
fit_predict(X) -> np.ndarray

• n_clusters: final number of clusters after merging.
• linkage: merge rule, one of "single", "complete", or "average".
• X: numeric feature matrix to cluster.

• Fitted attributes include labels_, clusters_, children_, and distances_.

MLP

MLP(n_inputs, layer_sizes, seed=None)
parameters() -> list[Value]
fit(X, y, *, epochs=100, learning_rate=0.05) -> list[float]
predict(X) -> np.ndarray

• n_inputs: input width expected by the network.
• layer_sizes: sizes of hidden layers followed by the output layer.
• seed: initialization seed for network weights.
• X: training or prediction inputs.
• y: training targets.
• epochs and learning_rate: training loop length and step size for fit().

• parameters() returns the model's learnable Value objects.
• fit() returns the loss history across epochs.
• Fitted attributes include loss_history_, n_inputs_, layer_sizes_, and layers.

Back to contents Next: Plotting

Plotting

Import plotting helpers from learnify.plotting. Each function returns a Matplotlib Figure.

Training And Linear Models

plot_loss_curve(loss_history, *, ax=None, title="Training loss")
plot_linear_coefficients(model, *, ax=None, feature_names=None, title="Weights and bias")
plot_regression_fit(model, X, y, *, ax=None, feature_name="x", target_name="y", title="Linear regression fit")
plot_binary_decision_surface(model, X, y, *, ax=None, feature_names=None, response="decision", title="Decision surface")
plot_discriminant_function(model, X, y=None, *, ax=None, feature_names=None, title="Discriminant function")

• loss_history: numeric training trace for plot_loss_curve().
• model: fitted linear or binary classification estimator.
• X and y: data to visualize.
• ax: optional existing Matplotlib axis.
• feature_names, feature_name, target_name, and title: display labels.
• response: whether the decision-surface plot shows raw scores or probabilities.

Trees And Forests

plot_decision_tree(tree, *, ax=None, feature_names=None, class_names=None, title="Decision tree")
plot_tree_feature_importances(tree, *, ax=None, feature_names=None, title="Decision tree feature importance")
plot_random_forest_feature_importances(forest, *, ax=None, feature_names=None, title="Random forest feature importance")
plot_random_forest(forest, *, feature_names=None, class_names=None, max_trees=4, title="Random forest overview")

• tree and forest: fitted estimators to draw.
• ax: optional existing axis for the single-plot helpers.
• feature_names and class_names: optional display labels.
• max_trees: number of trees to show in the forest overview.
• title: figure title.

Clustering

plot_kmeans_clusters(model, X, *, ax=None, feature_names=None, title="KMeans clustering")
plot_agglomerative_clusters(model, X, *, ax=None, feature_names=None, title="Agglomerative clustering")
plot_agglomerative_dendrogram(model, *, ax=None, leaf_labels=None, title="Agglomerative merge diagram")

• model: fitted clustering model.
• X: data to plot for the cluster scatter views.
• ax: optional existing axis.
• feature_names: axis labels for feature dimensions.
• leaf_labels: custom sample labels for the dendrogram.
• title: figure title.

Neural Networks

plot_mlp_architecture(model, *, ax=None, title="MLP architecture")
plot_mlp_weight_matrices(model, *, title="MLP weight matrices")
plot_mlp_predictions(model, X, y, *, ax=None, feature_name="x", target_name="y", title="MLP regression fit")

• model: fitted MLP instance.
• X and y: data for prediction visualizations.
• ax: optional existing axis where supported.
• feature_name, target_name, and title: display labels.

Back to contents Next: Notes

Notes

• Most model APIs accept NumPy arrays and reshape one-dimensional inputs into column vectors when needed.
• LogisticRegressionGD and LinearSVM currently support binary classification only.
• Several plotting helpers expect one or two input features, depending on the chart.
• Implementations favor readability over scikit-learn compatibility or production optimizations.
